Product Introduction
| OS | Android 12 | |
| CPU | Rockchip RK3588 (Octa Core; 2.4GHz) |
Cortex-A76×4
@2.4GHz Cortex-A55×4 @1.8GHz |
| GPU | ARM Mali G610 | |
| RAM/ROM | 8GB/256GB，16GB/256GB | 8GB/512GB, 16GB/512GB Optional |
| LCD | 10.1 inch; 1200*1920; 450nits | IPS Screen; 1000nits(1200*1920) Optional |
| Touch Screen | 10 Point Touch | Support stylus |
| Camera | Front: 5MP; Rear: 13MP | Flash light |
| Power and Battery | 6000mAh / voltage 7.6Vdc(45.6Wh) |
Charging
time: about 4 hours Usage time: 8H30min (50% volume, 60% brightness, playing local 1080P video) Standby time: about 43 days (screen off standby) |
| WWAN |
FDD_LTE:
B1/B2/B3/B4/B5/B7/B8/B28/B66 TDD_LTE: B40 WCDMA: B1/B2/B4/B5/B8 GSM: 850/900/1800/1900 |
Module: SLM770A |
| GPS | BDS, GPS, GLONASS | |
| WIFI |
802.11a/b/g/n/ac/ax
Wireless Internet Wireless AP ( Mobile AP )2.4G, 5G; Support WiFi6 |
WiFi/Bluetooth 2-in-1 |
| BLUETOOTH | 5.0 Version | |
| NFC | 13.56 MHz, Distance: 1-3cm | ISO/IEC 14443A |
| MIC |
Sensitivity: -32±2d Output Impedance: 2.2kΩx1 |
|
| SPEAKER | 8Ω 1.5 Watt | |
| Sensor |
1.
Light sensor 2. Magnetic sensor 3. Pressure sensor 4. G-sensor 5. Distance sensor 6. Acceleration sensor 7. Gyroscope |
|
| Size | 273*172*20mm | |
| Weight | 1150±50g | |
| Language | Multi language | |
|
Interface In/Out Port |
1. Type-C *1; OTG 2. SIM Card Slot*1 3. TF Card Slot*1 4. Earphone*1 5. DC*1; 4.0*15mm 6. USB-A：USB 2.0 *1+USB 3.0 *1 7. RJ45*1 8. RS232*1 9. HDMI*1 |
Bottom
pogopin: USB 2.0; Charging; RS232 Back pogopin: USB 2.0; RS232 |
| Button | V+ -, Power, "F" for Barcode Scan |
Customized
Button: P,H (Default No Functionality) |
| 1D/2D Barcode | Optional | Honeywell N4680 Optional |
| UHF RFID | Optional |
American standard M500 (902Mhz – 928Mhz) External: card reading distance of 3-5M |
|
European standard M500
(865MHz – 868MHz) External: Card reading distance of 3-5M |
||
| Fingerprint | Optional | AFM60 Optional |
| Accessories |
1.
Blue Box 2. DC Charger (12V 4A) 3. Carry strap 4. Screw 5. Wrist strap |
Optional: 1. Docking Station 2. Car Holder 3. Car Docking 4. Type-C 65W fast charging charger |
|
Multi-Media (Hardware Decoding) |
1. Photo Viewer: BMP, JPG, GIF, PNG 2. Video Format: MEPG 1/2/4,H.263/H.264, RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) 3. Audio Format: MP3,WMA,WAV,OGG,FLAC,ALAC, APE,AAC,AC-3,DTS (need license) |
|
| Proof Degree |
Anti-dust
& Waterproof IP65 Dropping Resistance 1.2 meters |
|
| Certification |
1.
MIL-STD-810G 2. ISO-9001 3. CE, FCC, 3C |
|
| Temperature |
Storate Temperature:
-25 °C to 80 °C Operation Temperature: -20 °C to 55 °C |
