Intel® Core™ i5-10210Y Processor (6M Cache, up to 4.00 GHz)
Essentials
Product Collection 10th Generation Intel® Core™ i5 Processors
Code Name Products formerly Amber Lake Y
Vertical Segment Mobile
Processor Number i5-10210Y
Status Launched
Launch Date Q3'19
Lithography 14 nm
Recommended Customer Price $292.00
CPU Specifications
# of Cores 4
# of Threads 8
Processor Base Frequency 1.00 GHz
Max Turbo Frequency 4.00 GHz
Cache 6 MB Intel® Smart Cache
Bus Speed 4 GT/s
TDP 7 W
Configurable TDP-up Frequency 1.30 GHz
Configurable TDP-up 9 W
Configurable TDP-down Frequency 600 MHz
Configurable TDP-down 5.5 W
Supplemental Information
Embedded Options Available No
Datasheet View now
Memory Specifications
Max Memory Size (dependent on memory type) 16 GB
Memory Types LPDDR3-2133, DDR3L-1600
Max # of Memory Channels 2
Max Memory Bandwidth 33.33 GB/s
ECC Memory Supported ‡ No
Processor Graphics
Processor Graphics ‡ Intel® UHD Graphics for 10th Gen Intel® Processors
Graphics Base Frequency 300 MHz
Graphics Max Dynamic Frequency 1.05 GHz
Graphics Video Max Memory 16 GB
Graphics Output eDP/DP/HDMI/DVI
Execution Units 24
4K Support Yes, at 60Hz
Max Resolution (HDMI)‡ 4096 x 2304@24Hz
Max Resolution (DP)‡ 3840 x 2160@60Hz
Max Resolution (eDP - Integrated Flat Panel)‡ 3840 x 2160@60Hz
DirectX* Support 12
OpenGL* Support 4.5
Intel® Quick Sync Video Yes
Intel® Clear Video HD Technology Yes
Intel® Clear Video Technology Yes
# of Displays Supported ‡ 3
Device ID 0x87CA
Expansion Options
PCI Express Revision 3
PCI Express Configurations ‡ 1x4, 2x2, 1x2+2x1 and 4x1
Max # of PCI Express Lanes 10
Package Specifications
Sockets Supported UTFCBGA1377
Max CPU Configuration 1
TJUNCTION 100
Package Size 26.5mm x 18.5mm
Advanced Technologies
Intel® Speed Shift Technology Yes
Intel® Thermal Velocity Boost No
Intel® Turbo Boost Technology ‡ 2
Intel vPro® Platform Eligibility ‡ No
Intel® Hyper-Threading Technology ‡ Yes
Intel® Virtualization Technology (VT-x) ‡ Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
Intel® Transactional Synchronization Extensions No
Intel® 64 ‡ Yes
Instruction Set 64-bit
Instruction Set Extensions Intel® SSE4.1
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Thermal Monitoring Technologies Yes
Intel® Flex Memory Access Yes
Intel® Identity Protection Technology ‡ Yes
Intel® Stable Image Platform Program (SIPP) No
Intel® My WiFi Technology Yes
Security & Reliability
Intel® AES New Instructions Yes
Secure Key Yes
Intel® Software Guard Extensions (Intel® SGX) Yes with Intel® ME
Intel® Memory Protection Extensions (Intel® MPX) Yes
Intel® Trusted Execution Technology ‡ No
Execute Disable Bit ‡ Yes
Intel® OS Guard Yes
Intel® Boot Guard Yes
