Product Introduction
| OS | Android 15 | Support GMS |
| CPU | MT6877, Octa Core; 2.4GHz |
2 × Arm Cortex-A78，Frequency up to 2.4GHz 6 × Arm Cortex-A55，Frequency up to 2.0GHz |
| RAM/ROM | 8GB/256GB | 16GB/512GB Optional |
| LCD | 13.3 inch; 1080*1920; 400nits | IPS |
| Touch Screen | 10 Point Touch | Support stylus |
| Camera | Front: 8MP; Real: 16MP | Flash light |
| Power and Battery | 16000mAh / voltage 3.8Vdc (60.80Wh) | |
| WWAN |
5G：N1/N5/N8/N28AB/N78/N41 FDD_LTE: B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28 TDD_LTE: B34/B38/B39/B40/B41/B66 WCDMA: 850/900/1900/2100 CDMA2000: BC0 TD-SCDMA: B34/B39 GSM: 850/900/1800/1900 |
|
| GPS | BDS, GPS, GLONASS | |
| WIFI |
802.11a/b/g/n/ac/ax
wireless internet Wireless AP ( Mobile AP )2.4G, 5G |
Support WIFI 6 |
| BLUETOOTH | 5.2 Version, backward compatible | |
| NFC | 13.56 MHz, Distance: 1-3cm | ISO14443 TYPE A; Mifare |
| MIC |
Sensitivity: -32±2d Output Impedance: 2.2kΩx1 |
|
| SPEAKER | 8Ω 1.0 Watt *2 | |
| Sensor |
1.
Light Sensor 2. Geomagnetic Sensor 3. Barometric Sensor 4. G-Sensor 5. Acceleration Sensor 6. Gyroscope 7. Distance Sensor 8. Vibrate (motor) |
|
| Size | 330*205*19.5mm | |
| Weight | 1450 ± 50g | |
| Language | Multi language | |
|
Interface In/Out Port |
1. DC power interface：DC ∮3.5mm
power interfac 2. USB-A：USB 2.0 *1 3. Type-c*1 4. Anti-theft lock hole 5. Aviation interface x2: customized interface & RS232 (RS232 not fully functional, only TX RX GND) 6. Card slot: SIM card slot+TF card slot 7. Headphone Jack：∮3.5mm Standard headphone interface 8. Ethernet RJ45：10/100M |
Bottom pogopin: USB 2.0; RS232; Charging |
| Button | V+ -, Power, "F" for Barcode Scan |
Customized
Button: P, H (Default No Functionality) |
| 1D/2D Barcode | Optional | Honeywell N4680 Optional |
| Accessories |
1.
Blue Box 2. DC Charger (5V 3A) 3. Carry strap 4. Screw 5. Wrist strap |
|
|
Multi-Media (Hardware Decoding) |
1. Photo Viewer: BMP, JPG, GIF, PNG 2. Video Format: MEPG 1/2/4,H.263/H.264, RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) 3. Audio Format: MP3,WMA,WAV,OGG,FLAC,ALAC, APE,AAC,AC-3,DTS (need license) |
|
| Proof Degree |
Anti-dust
& Waterproof IP65 Dropping Resistance 1.2 meter |
|
| Certification |
1.
MIL-STD-810G 2. ISO-9001 3. CE, FCC, 3C |
|
| Temperature |
Storate Temperature:
-25 °C to 80 °C Operation Temperature: -20 °C to 55 °C |
