Product Introduction
| ITEM | DESCRIPTION | DETAIL |
| OS | Android 12 | |
| CPU | Rockchip RK3588 (Octa Core; 2.4GHz) |
Cortex-A76×4
@2.4GHz Cortex-A55×4 @1.8GHz |
| GPU | ARM Mali G610 | |
| RAM/ROM | 8GB/256GB，16GB/256GB | 8GB/512GB, 16GB/512GB Optional |
| LCD | 13.3 inch; 1080*1920; IPS | |
| Touch Screen | 10 Point Touch | |
| Camera | Front: 5MP; Real: 13MP | |
| Power and Battery | 8000mAh / voltage 7.6Vdc (60.80Wh) | 6000mAh optional |
| WWAN |
4G
Fre: FDD_LTE: B1/B2/B3/B4/B5/B7/B8/B28/B66 TDD_LTE: B40 WCDMA: B1/B2/B4/B5/B8 GSM/EDGE: B2/B3/B5/B8 |
Module: SLM770A |
| GPS | BDS, GPS, GLONASS | |
| WIFI |
802.11a/b/g/n/ac/ax
wireless internet Wireless AP ( Mobile
AP )2.4G, 5G Support WIFI 6 |
WiFi/Bluetooth 2-in-1 |
| BLUETOOTH | 5.0 Version | |
| NFC | 13.56 MHz, Distance: 1-3cm | ISO14443 TYPE A |
| MIC |
Sensitivity: -32±2d Output Impedance: 2.2kΩx1 |
|
| SPEAKER | 8Ω 1.0 Watt *2 | |
| Sensor |
1.
Light sensor 2. Magnetic sensor 3. Pressure sensor 4. G-sensor 5. Distance sensor 6. Acceleration sensor 7. Gyroscope |
|
| Size | 330*205*19.5mm | |
| Weight | 1450 ± 50g (for reference only) | |
| Language | Multi language | |
|
Interface In/Out Port |
1.
HDMI Type A*1 2. USB-A：USB 2.0 *1+USB 3.0 *1 3. Type-c*1 4. Anti-theft lock hole 5. Aviation interface x2: customized interface & RS232 (RS232 not fully functional, only TX RX GND) 6. Card slot: SIM card slot+TF card slot 7. Headphone Jack：∮3.5mm Standard headphone interface 8. Ethernet RJ45：10/100/1000M 9. DC power interface：DC ∮4.0mm power interface |
Bottom pogopin: USB 2.0; Charging; RS232 |
| Button | V+ -, Power, "F" for Barcode Scan |
Customized
Button: P, H (Default No Functionality) |
| 1D/2D Barcode | Optional | Honeywell N4680 Optional |
| Accessories |
1.
Blue Box 2. DC Charger (12V 4A) 3. Carry strap 4. Screw 5. Wrist strap |
|
|
Multi-Media (Hardware Decoding) |
1. Photo Viewer: BMP, JPG, GIF, PNG 2. Video Format: MEPG 1/2/4,H.263/H.264, RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) 3. Audio Format: MP3,WMA,WAV,OGG,FLAC,ALAC, APE,AAC,AC-3,DTS (need license) |
|
| Proof Degree |
Anti-dust
& Waterproof IP65 Dropping Resistance 1.2 meter |
|
| Certification |
1.
MIL-STD-810G 2. ISO-9001 3. CE, FCC, 3C |
|
| Temperature |
Storate Temperature:
-25 °C to 80 °C Operation Temperature: -20 °C to 55 °C |
