Product Introduction
| items | Details | Descrption |
| Style | Narrow border NoteBook | |
| SIZE | 362*238*20mm | |
| Material | Aluminum alloy | |
| Color | Gray | |
| Panel size | 15.6 inches 1920*1080 16:9 eDP FHD | |
| Weight | about 1.78KG | |
| System Configuration | ||
| items | Details | Descrption |
| CPU | intel | 11th Generation Intel® Core Tiger Lake UP3 1115G4、1135G7、1165G7 etc. |
| GPU | intel |
Intel®
Iris® Xe Graphics Nvidia MX450 2G（option） |
| RAM | DDR4 | DDR4 \3200MHz, one SO-DIMM slot support DDR4 up to 32GB |
| SSD | M.2 SSD |
Support
one M.2 22*80 SSD Support PCIE and SATA signal bus |
| Network | ||
| items | Details | Descrption |
| WIFI | WIFI module |
M.2 interface, Support 802.11B/G &
802.11B/G/N&AC two Wireless antenna Bluetooth 4.0 2-in-1 WIFI &BT combo card |
| RJ45 | RJ45 | NA |
| I/O Configuration | ||
| items | Details | Descrption |
| USB port | Standard USB port | 2*USB3.0 , 2*USB2.0 |
| Audio jack | Audio Jack | ∮3.5mm 1 Jack, MIC in/ Line out |
| DC jack | power in | ∮5.5mm Power connect |
| HDMI port | HDMI port | support HDMI1.4 |
| Type C port | Type port | support USB3.0 |
| Camera | inner Camera | 2.0M Camera |
| Card Reader | inner Card Reader | 2IN1 SD/MMC |
| Speaker | inner Speaker | 2 stereo Speakers |
| Microphone | inner Microphone | one analog microphone |
| touchpad | inner touchpad | Yes (multi touch) |
| keyboard | inner keyboard | Chocolate keyboard and keyboard Backlight |
| Accessories | ||
| items | Details | Descrption |
| Power adapter | 19V 3.42A power adapter | 65W adapter (90w adapter for NV Graphaic) |
| battery | inner Battery | 3Cells 3S1P 5000mAh 11.4V |
| software | ||
| items | Details | Descrption |
| OS | OS | Support Win8.1/Win10/ win11/linux/Ubuntu etc |
