Product Introduction
| OS | Android 9.0 (support Google play) or Android 11.0 (support GMS) | ||
| CPU | MTK P60 MT6771 Octa A73 core 2.0 GHz | ||
| RAM/ROM | 8GB/128GB OR 6GB/128GB, OR 4GB/64GB | ||
| LCD | 10.1 inch1920*1200； | 500 nits sunshine readable | |
| Touch screen | 10 point touch, support stylus | ||
| Camera | 5M/13M, flash | 5M/13M, flash | |
| Power and battery | battery total capacity 10500mAh |
8400mAh,hotswap, 2100mAh backup power 3.8V 3A imput, support hotswap |
|
| 3.5*1.35mm, 5V 3A DC in put | Magnetic charger | ||
| WWAN | 4G LTE, 3G WCDMA, GSM |
4G Fre: FDD: B1,B2, B3,B5, B7, B8, B12， B20 TDD: B38,B39,B40,B41 B34 WCDMA:B1, B8 TD-SCDMA: B34, B39 GSM/GPRS/EDGE |
|
| GPS | baidou,GPS, glonass | ||
| wifi | 802.11a b c, g,n wireless internet Wireless AP ( Mobile AP )2.4G, 5G | ||
| BLUETOOTH | 4.0 version | ||
| NFC | 13.56 MHz, distance 5cm or above | ||
| SPEAKER | 1.5 watt | ||
| Sensor |
1. light sensor 2. compass 3. gravity 4. acceleration 5. baroceptor |
||
| size | 275*178*18mm | ||
|
Multi-media (Hardware decoding) |
Photo Viewer | BMP, JPG, GIF, PNG | |
| Video Format | MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) | ||
| Audio Format | MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license) | ||
| language | multi language | ||
|
interface in/out port |
1. normal USB*1 2. Micro USB*1 3. RJ45*1 4. bottom pogopin*1, USB and serial 5. back pogopin*1 6. DC*1 3.5*1.35 7. microphone+earphone 8. RS232*1 |
||
| Pogopin definition |
1.16pin back of cover, include （1USB, 1 RS232， 1 UART， 3.3V, 5V OUT) 2. 8pin in bottom； （1USB, 1 RS232， 1 UART， ) VESA hole 75*75mm or 90*90mm |
||
| casing material | ABS/PC | ||
| button | V+ -, Power, P, F, H | ||
| 2D barcode module | honeywell N3680 | optional | |
| UHF | reading and write distance 1meter to 10 meter | optional | |
| fingerprint module | LD-8800-M | optional | |
|
standard accessories in gift box |
1. USB cable 2. charger( 4-in-1) 3. handstrap 4. handstring 5. white box, no logo |
||
|
optional accessories |
1. car docking 2. extra battery 3. screen protective film 4. car holder 5. docking station 6. car charger |
||
| proof rate |
1. water proof IP65 2. Drapping proof 1.2 meter |
||
| Certification |
1. 810G 2. CE,FCC |
||
| Temperature |
1. storate temperature -25 to 80 degree 2. operation temperature -20 to 60 degree |
