Product Introduction
| ITEM | DESCRIPTION | detail |
| OS | Windows 10 PRO | Windows 11 optional |
| CPU |
Intel
N5100 4 cores, 4 threads/basic frequency 1.1GHz, turbo 2.8GHz/power consumption 6W |
|
| GPU | Intel® Iris® Xe Graphics 80EU | Intel® Iris® Xe Graphics 96EU |
| RAM/ROM |
RAM：4GB/8GB(max 16) ROM: 128GB/256GB/512GB |
|
| LCD |
10.1 inch 1920*1080 Max 450nits |
|
| TP |
Supports
10 touch control Supports thin glove touch |
Chip：GT9110 |
| Camera | 5M/8M | 5M/13M optional |
| Battery | 6000mAh，7.6V lithium battery (45.6Wh) | |
| DC4.0*1.7mm，12V 4A DC input | Supports Type-C 65W fast charging | |
| LTE |
4G
Fre: FDD: B1,B2, B3, B4, B5, B7, B8, B28 TDD: B40 WCDMA:B1, B2,B4,B5,B8 GSM: B2, B3, B5, B8 |
|
| GPS | baidou,GPS, glonass | Model：ZP820P |
| WIFI | 802.11b/g/n/ac/ax wireless internet Wireless AP ( Mobile AP )2.4G, 5G |
Model：AX201D2W，Integrated
Bluetooth support WIFI 6 |
| Bluetooth | Version 5.2, backward compatibility | Bluetooth/WIFI 2-in-1 |
| Speaker | 8Ω 1.5W x2 | |
| Sensor |
1.
Light sensor 2. Acceleration sensor 3. Gravity sensor |
|
| Size | 330*205*19.5mm | |
| Weight | 1300g±100g | |
| Multi-media | Photo Viewer | BMP, JPG, GIF, PNG |
| Video Format | MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (max 1080P) | |
| Audio Format | MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license) | |
| Language | multi language | |
| Interface |
1.
DC 12V 3A ∮4.0mm x2 2. HDMI Type A x1,Audio and video output 3. USB Type_A：USB3.2 Gen1 x2 4. USB Type_C：USB3.2 Gen1 x1(type-c include PD, DP, Data transmission, Charging) 5. SIM/TF card slot 6. RJ45：Support Gigabit Ethernet 7. Aviation socket x2: RS232 & undefined interface (reserved) 8. Earphone：∮3.5mm headphone jack x1 |
|
| Pogopin | Bottom 16PIN：USB2.0 x1+RS232 x1+charging | |
| Button | V+ -, Power, P, F, H | P/H is a customizable function key, while F defaults to the scanning key |
| NFC | ISO/IEC14443，ISO/IEC15693，MIFARE | optional |
| Scanner | honeywell N4680 | optional |
| UHF | M500 | optional |
| Fingerprint | AFM60 | optional |
| Customized Items | Mobile communication: 5G | |
| Accessories |
1.
TYPE-C data cable 2. Adapter (PD protocol) 3. 12V4A DC adapter optional |
|
|
Certification Standards |
1.
EU CE, US FCC 2. All materials used must comply with ROHS standards |
|
|
ESD Static Electricity Test |
Air
discharge ≤ 6KV, Contact discharge ≤ 4KV |
|
|
High and Low Temperature Testing |
Operate temperature： -10℃ to 50℃ |
