Product Introduction


FEATURES(Ultra-thin Rugged tablet)

u  Advanced system

Android 8.1 operating system; Qualcomm, 8 core, 1.8GHz CPU/A53; RAM:3G FLASH:32G, Micro SD, Maximum 128G

u  Visible under strong light

8 inch LCD screen, 1920x1200 IPS capacitive touch screen

u  Optional functions

Multifunction1D/2D bar code scanning

-HF/UHF RFID reader

-Fingerprint identification(Front)

-High precise GPS

Wireless Charging

u  Multi communication modes

3G/4G, WIFI, Bluetooth, dual SIM card


Support jacket extension

Satisfy custom applications from customers

u  Certification

CCC/CE/ROSH/FCC/IP67/MIL-STD-810

SPECIFICATIONS

Standard function

Operating System

Android 8.1 operating system

CPU

Qualcomm SD630,CPU 1.8GHz/A53 Qcta core

Memory

RAM: 3GB  FLASH: 32GB

Extended Storage

Micro SD, Maximum 128G

USB port

5 pin MicroUSB; Support to connect U-disk/Mouse/Keyboard/OTG line

OTG

OTG extend RS232 serial port/485 serial port/RJ45 Serial port

External port

Charge port, headphone port

Protection Grade

Industrial Protection Grade

IP65

Drop Grade

Drop resistance from 1.2m

Wireless Communication

Bluetooth

Support 4.0

GPS

--GPS+BDS+A-GPS+GLONASS,10m

WIFI

--802.11a/b/g/n/ac (2.4G and 5G bands)

2G/3G/4G

4G LTE: LTEB1/B3/B5/B7/B8/B20/B26/B34/B38/B39/B40/B41

WCDMA: B1/B2/B5/B8

GSM: B2/B3/B5/B8

TD-SDMA: 34/39

CDMA 1X/EVDO:BC0

Band38:2570 MHz - 2620 MHz

Band39: 1880 MHz - 1920 MHz

B41:2555-2655MHz

B40/:2300-2400MHz B38/B39/B41/B40/  B38/B39/B40/B41

Physical Parameters

Display Screen

8 inch LCD screen1920*1200 IPS screen, capacitive touch screen

Keyboard

Android menu, Homepage, Return, Volume+/-, Barcode, ON/OFF

Camera

5 million pixels front camera, 13 million pixels rear camera with automatic focus and lighting function

Headset

   3.5mm audio Interface, has MIC and Single loudspeaker

LED indicator light

   Support (ordinary flicker, Call fast flicker, missed calls, charge indicator)

Flashlight Function

S  Support, can be used for emergency lighting

   Googleplay store

S  Support

Gravity sensor

Support

Compass

Support

Gyroscopes

NOT Support

Acceleration sensors

Support

Light and distance sensor

Support

Vibrating motor

Support

FM

Support

Rechargeable Lithium Battery

3.8V, 6000mAh; Standby about 500 hours

Support Qi protocol wireless charging and USB QC3.0 fast charge.

Dimension

229.4*136.2*11.5mm

Weight

510g

Environmental Characteristics

Working Temperature

-20 ~ +55

Storage Temperature

-40 ~ +60

Humidity

5%-95% relative humidity; no condensation

Optional function

Fingerprint identification

Front fingerprint identification (fingerprint unlocking)

Type: AuthenTec TCSIST semiconductor sensor

Acquisition window size: 24.5*19mm

Effective image size:15.5*18.5mm

Sensor type: capacitive

Image size: 256*360 pixel

Resolution: 500 DPI

Matching mode: contrast mode(1:1); search mode(1:N)

Barcode Scanning

1D Laser Scanner Index(In Jacket):

Honeywell N4313 or Zebra EM1350

Scanning speed: 104 times/second+12 times/second (two way scanning)

Scanning distance: 2.5cm-114.3cm

Scanning angle: 47±3°(default) /35±3°(reduced code)

2D Barcode Scanner Index(In Jacket):

Newlands EM3096 Or Honeywell N3680

Identification ability: 1D, 2D, OCR

Scanning angle: rotate 360°, incline±50°, deflection ±50°

Field of View: Horizontal 36°, vertical 23°

Depth of field: 4cm-23.5cm

Environmental luminance: 0~100,000 LUX

2D Barcode Scanner Index(In Host):

Zebra SE2100

RFID

HF RFID(Internal): HF RFID(In Host):Support Mifare Classic 1 card

Support NFC/NXP, 13.56MHZ ISO14443A,B and ISO15693 protocol, reading distance 0-3cm

UHF RFID(In Jacket):

Supports EPC C1 GEN2/ ISO 18000-6C and ISO 18000-6B/6C protocol

Reading distance:1.8m/3.5m

Frenquency:865-868Mhz or 920-925Mhz

Ceramic antenna: 0.3db(25*25*4mm)

High Precise GPS

High Precise GPS Locating Module with accuracy <3m

Infrared Communication

 Infrared Communication Working frequency 37.9K
