Product Specifications |
|
|
Performance |
|
|
Octa Core |
|
|
CPU |
MT6762 Octa core 64 bit 2.0 GHz high performance processor |
|
RAM+ROM |
2GB+16GB / 4GB+64GB |
|
Expand memory |
Micro SD(TF) Supports up to 256GB |
|
System |
|
|
Data Communication |
|
|
WLAN |
Dual-band 2.4GHz / 5GHz, Support IEEE 802.11ac/a/b/g/n/d/e/h/i/j/k/r/v protocol |
|
WWAN |
2G：GSM（850/900/1800/1900MHz） |
|
3G：WCDMA（850/900/1900/2100MHz） |
|
|
4G：FDD:B1/B3/B4/B7/B8/B12/B20 TDD:B38/B39/B40/B41 |
|
|
Bluetooth |
Support Bluetooth 5.0+BLE Transmission distance 5-10 meters |
|
GNSS |
Support Gps, Galileo, Glonass, Beidou |
|
Physical Specifications |
|
|
Dimensions |
179mm×74.5mm×150mm（Including the handle） |
|
Weight |
＜750g (Depends on device function configuration） |
|
Display |
5.5 "color display with resolution 720×1440 |
|
Screen brightness |
＞500cd/m2 |
|
TP |
support multi-touch |
|
Battery capacity |
Rechargeable polymer battery 7.6V 4000mAh (Equal to 3.8V 8000mAh) ,removable |
|
Standby time >350 hours |
|
|
Charging time ＜3H, using standard power adapter and data cable |
|
|
Expansion Card slot |
NANO SIM card x1、TF card x1（Optional PSAMx2）、POGO Pinx1 |
|
Communication interface |
Type-C 2.0 USB x 1, supporting OTG function |
|
Speaker volume |
＞92db (test distance 10cm) |
|
Audio |
Speaker (mono), Microphone,Receiver |
|
Main keys |
Home key, Delete key, Back key,Confirm key |
|
Side keys |
Silicone keys: Power key, Volume +/- key, Handle scan key,Scan key ×2 |
|
Sensors |
Gravity sensor, light sensor, distance sensor, vibration motor |
|
Data Collection |
|
|
Barcode Scanning (Optional) |
|
|
2D Scanning engine |
Honeywell N6703 N5703,N6602-W2 |
|
1D Symbologies |
UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS,etc. Postal Codes:USPS Planet, USPS Postnet, China Post, Korea Post, Australian Postal, Japan Postal, Dutch Postal (KIX), Royal Mail, Canadian Customs,etc. |
|
2D Symbologies |
PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, HanXi,etc. |
|
Camera（Standard） |
|
|
Rear camera |
13MP pixel HD camera Support auto focus, Flash, Anti-shake, Macro shooting |
|
Front camera |
2MP pixel color camera |
|
NFC (Optional) |
|
|
Frequency |
13.56MHz |
|
Protocol |
Support ISO14443A/B, 15693 agreement |
|
Distance |
2cm-5cm |
|
UHF (Optional) |
|
|
Engine |
|
|
Frequency(CHN) |
920-925MHz |
|
Frequency(USA) |
902-928MHz |
|
Frequency(EHR) |
865-868MHz（ETSI EN 302 208） |
|
Frequency(Other) |
Other multinational frequency standards (can be customized) |
|
Protocol |
EPC C1 GEN2/ISO18000-6C |
|
Antenna |
Circularly polarized antenna (4.65dBi) |
|
Distance |
0-20m |
|
Reading speed |
>500 tags per second (circular polarization) |
|
Language/Input Method |
|
|
Input |
English, Pinyin, Five strokes, Handwriting input, Support soft keypad |
|
Language |
Language packs in Simplified Chinese, Traditional Chinese, English, Korean, Japanese,Malaysian,etc. |
|
User Environment |
|
|
Operating temperature |
-20℃ - 55℃ |
|
Storage temperature |
-40℃ - 70℃ |
|
Environment humidity |
5%RH--95%RH(no condensation) |
|
Drop specification |
6 sides supports 1.2 meters drops on the marble within the operating temperature |
|
Rolling test |
0.5m rolling for 6 sides, can still work steadily |
|
Sealing |
IP65 |
|
Accessories |
|
|
Standard |
Adapter, Data cable, Protective film, Instruction manual |
|
|
|
