Product Introduction
| ITEM | SPECIFICATION | Remark |
| OS | Android 14/ Linux Ubantu 20.04 Dual OS optional | Android 14/ Linux Ubantu 20.04 Dual OS optional |
| CPU | RK3588 (8 cores: 4 Cortex-A76 cores at 2400 MHz and 4 Cortex-A55 cores at 2200 MHz) | |
| Ethernet LAN RJ45 | 2*RJ45,1000Mbps*1, 100Mbps*1 | 1 RJ45 support POE |
| RAM Memory | 16GB | 32GB/8GB optional |
| EMMC | 128GB | |
| SSD | 512GB SSD | 1TB/2TB optional |
| SPI Nor flash | Nor flash for boot load | |
| LCD display | 10.1 inch， resolution 1200*1920，1000 nits | |
| Touch panel |
10
point touch panel Panda MN228 cover glass |
|
| Camera | Front 8M/Back real 20M | |
| battery |
8000mAh*7.6V
smart battery Equel =16000mAh*3.8V |
|
| RTC battery | for saving time. Make real time | |
| charging |
TYPE-C，fual
function，support 65W DC4.0， 12V Charging |
|
| 4G |
Meige
770A support calling function and Message |
|
| wifi |
IEEE
802.ac, IEEE 802.11b, IEEE 802.11a, IEEE 802.g, IEEE 802.n Support WIFI 2.4ГГц, 5ГГц support WiFi 6.0 |
|
| GPS | Beidou/GPS/GLONASS | |
| BT | BT5.0 or above | |
| NFC | support, in battery | |
| Interface I/O port |
1.
USB Type_c (USB 3.0) with USB OTG support (specify) full function 2. USB-A 3.0 * 2 3. Headphones jack 3.5 mm 4. HDMI（±14*4.6mm full-size）port 5. 1*SIM slot，dual SIM card 6. 1*TF slot 7. mini USB*1 for Uart Sinal 8. RJ45*2,one support POE |
|
| Sensor |
Microphone, -Light sensor, -Accelerometer, -Cameras, -Flashlight -Compass. |
|
| Finger print | support optional | |
| Identity Module | support optional | |
| UHF | support optional | |
| 2D barcode | support optional | |
| high precision GPS | support optional | |
| Stylus pen | in the tablet | |
| pogopin | 16*pin pogopin on the bottom | |
| Flash light | support | |
| water proof | IP66 | |
| Temperature |
working
-20 to 55 Storage: -25 to 70 |
|
| Droping proof | 1.2 meter | |
