Product Introduction
OS windows 10/11 home/pro/iot linux optional
CPU intel ADL-N， N100， optional N200 optional
RAM/ROM 8GB/256GB, OR 16GB/512GB optional
LCD 6.5inch 720*1600 410nits 6.5 inch optional
Touch screen 10 point touch,
Camera 5M+13M，mipi I/O
Power and battery battery capacity 5000mAh, 7.6V
-------------------------------------------------------------------------------------------------------------------------------------
WWAN "4G LTE, 3G WCDMA, GSMEC25AUX(South america, AU, NZ)
B1/2①/3/4/5/7/8/28/40" "EC25-EU(Europe, Tailand) optional
B1/3/7/8/20/28A, B38/40/41
EC25-AF(North america)
B2/4/5/12/13/14/66/71"
-------------------------------------------------------------------------------------------------------------------------------------
GPS baidou,GPS, glonass
wifi "802.11a b c, g,n, ac/ax wireless 2.4G, 5.2G,
Support wifi 6" intel WI-FI 6 AX201
BLUETOOTH 5.0 version
NFC 13.56 MHz, distance 5cm or above
-------------------------------------------------------------------------------------------------------------------------------------
SPEAKER 1.0 watt
Sensor "1. light sensor
2. G-sensor"
size 180*85*22mm
weight 0.5kg
"Multi-media
(Hardware decoding)" Photo Viewer BMP, JPG, GIF, PNG
Video Format MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P)
Audio Format MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license)
language 语言 multi language
-------------------------------------------------------------------------------------------------------------------------------------
"interface
in/out port
（接口说明）" "1. type-c，support quick charge
2. USB 3.0*2
3. bottom charging pogopin 8 pin（4pin for charge）
4. microphone
5. TF MAX512G
6. SIM card*2 or 1 TF+1*SIM card"
Pogopin definition 1. 4pin for charging， total 8 pin
casing material ABS/PC
button V+ -, Power, scan
2D barcode module SE550 or Newland N1
UHF M500, distance 3-6 meter
accessories "1. USB cable optional
2. charger
3. handstrap
4. car holder optional
5. docking station optional
6. car charger optional
7. white box, no logo"
proof rate "1. water proof IP65-IP67
2. Drapping proof 1.2 meter"
Certification "1. 810G
2. CE,FCC"
Temperature "1. storate temperature -25 to 80 degree
2. operation temperature -20 to 60 degree
"
