Product Introduction
ITEM CONTENT DETAIL
OS android 10
CPU "Unisoc T7510,
8 CORE A75， 4 core 2.0GHz， 4 core 1.8GHz"
RAM/ROM EMCP:8GB+256GB 4GB/64GB OPTIONAL
LCD "8 inch， 1920*1200；
" max brightness 400 nits
touch panel 10 point touch（10 point）
camera front 5M, back 13M
power charger Battery total 7800mAh
charger 3.5*1.35mm, 5V 3A DC in put
---------------------------------------------------------------------------------------------------------------------------------------------
WWAN "2G GSM：850/900/1800/1900；
3G WCDMA：B1/2/5/8；
4G LTE：B1/2/3/5/7/8/34/38/39/40/41；
5G：N41/N78/N79"
GPS beidou+GPS+glonass
wifi 802.11a/b/g/n， AC, Wireless AP ( Mobile AP )2.4G, 5G
bluetooth 5.0 version
NFC NFC module, fuction optional, can support carrie return, mifare desfire, module is optional can built in fron or back
---------------------------------------------------------------------------------------------------------------------------------------------
SPEAKER 1.5W
Sensor light sensor support
Geomagnetic Sensor support
Gyro sensor support
accelerometer support
Barometric sensor support
Dimension 234*144*16.8mmmm
---------------------------------------------------------------------------------------------------------------------------------------------
"Multi-media
(Hardware decoding)" picture Photo Viewer
video Video Format
audio Audio Format
language multi language
---------------------------------------------------------------------------------------------------------------------------------------------
"interface
（接口）" USB3.0 1 port
USB（pogopin） 1 port
Type-C USB 1 port
RJ45 1 port
URAT 3 set on pogopin
RS232 1 port
DC 3.5MM 1 port
3.5mm ear phone hole 1 port
Pogopin 16PIN on back cover
8PIN on back cover
button V+ -, Power, P, F, H F for scanner， P-enter，H-home
---------------------------------------------------------------------------------------------------------------------------------------------
bacode scanner N1 Optional
fingerprint LD-8800-M Optional
UHF RFID range 3-8 meter Optional
high precision GPS 0.25-1 meter, support beidou, GPS, GLONASS Optional
---------------------------------------------------------------------------------------------------------------------------------------------
Proof rate "1. water proof IP65，
2. Dropping proof 1.2 meter"
certification "1. 810G
2. CE, FCC
3. ROHS"
temperature "1. storage -25 degree to 80 degree
2. operate -20 degree to 60 degree
"
humidity no limited
