Product Introduction
Model: M8A-10210U
CPU: Onboard Intel Comet Lake Refresh Intel Core i5-10210U Processor, 6M Cache, 1.6GHz up to 4.20GHz (Turbo boost Technology) 4 Cores 8 Threads TDP 15W Intel® UHD Graphics.
Product Highlight:
- Brushed Full aluminum alloy case, compact structure and fanless system no any noise.
- Support 2 x DDR4 RAM slot, max 64GB DDR4 RAM.
- Dual Gigabit Ethernet and 2 x RS232 COM ports.
-Support HDMI2.0(Audio&Video support)+ HDMI 1.4(Middle, Video output only)+ DP 1.2(Video output only) three displays outputs.
-Support MSATA SSD+M.2 slot for NVME 2280 SSD and 2.5inch SATA3.0 HDD together.
- Multiple processors can be customized for bulk order such as Celeron 5205U, Pentium,5405U/6405U, Core i3-8145U, Core i5-8265U/8365U/8269U, Core i7-8565U/8569U,Core i3-10110U, Core i5-10210U/10310U, Core i7-10510U/10610U/10710U.
|
Basic Information: |
Input/output port： |
||
|
CPU |
Refer to the CPU |
Switch |
1 x Power On/Off Switch |
|
TDP |
Refer to the CPU |
Power |
1 x 12V DC In |
|
BIOS |
AMI EFI BIOS |
LED |
2 x LED |
|
Chipset |
Refer to the CPU |
USB |
4 x USB3.0 |
|
|
Display |
1 x HDMI 2.0(Audio&Video support), 1 x HDMI 1.4(Middle, Video output only),1 x DP 1.2(Video output only) |
|
|
Memory |
2 x SO-DIMM DDR4 Slot Support 4GB/8GB/16GB/32GB/64GB DDR4-2133/2400MHz |
LAN |
2 x RJ45 Giga LAN |
|
OS |
Windows®8/10, WES10, LINUX |
Audio |
1 x Headphone jack, 1 x Microphone |
|
PXE |
YES |
COM |
2 x RS232 COM |
|
Network |
2 x Onboard RTL8111 Gigabit Ethernet NIC 10/100Mbps/1000Mbps BaseT LAN |
Others |
2 x Kensington Lock holes |
|
Video |
Refer to the CPU |
|
|
|
Wi-Fi: |
Storage: |
||
|
Module |
1 x MSATA-half slot for WiFi & Bluetooth module |
MSATA |
1 x M-SATA3.0 slot for MSATA SSD, support 6Gb/s |
|
Antenna |
2 x inner RF cables and 2 x external antennas |
M.2 |
1 x M.2 slot for NVME 2280 SSD |
|
Power and Working Environment: |
SATA |
1 x SATA3.0 slot for SATA HDD or SSD, , support 6Gb/s |
|
|
Input |
100-240V AC/50-60Hz |
Product Dimension & Details: |
|
|
Output |
DC+12V~+19V, recommend 12V/5A |
Size |
178.3x127.5x55.0mm |
|
Operating Temperature |
-20°C/+60°C |
Weight |
Net 2kg, Gross 2.5kg |
|
Storage Temperature |
-30°C/+70°C |
Shell |
Black color aluminum alloy(any customized color for bulk order) |
|
Relative Humidity |
10%~95% @30(non-condensing) |
Cooling Mode |
Fanless, no cooling fan |
|
|
Functions |
PXE, Auto Power On, RTC |
|
|
Package Content： |
|||
|
Standard |
1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag |
||
|
Optional |
Wi-Fi antennas, 1xHDMI cable, 1xUser Manual, 1xVESA mount & screws |
||
